Size |
SM (Low, X-Low)
|
MD (Low, X-Low)
|
LG (Low, X-Low)
|
XL (Low, X-Low)
|
---|---|---|---|---|
Top Tube Length |
598mm
|
619mm
|
640mm
|
661mm
|
Head Tube Angle |
65.6°, 64.8°
|
65.6°, 64.8°
|
65.6°, 64.8°
|
65.6°, 64.8°
|
Head Tube Length |
100mm
|
114mm
|
127mm
|
141mm
|
Seat Tube Angle |
74.3°, 73.4°
|
74.3°, 73.4°
|
74.3°, 73.4°
|
74.3°, 73.4°
|
Seat Tube Length |
390mm
|
425mm
|
460mm
|
495mm
|
Bottom Bracket Height |
346.0mm, 334.4mm
|
346.0mm, 334.4mm
|
346.0mm, 334.4mm
|
346.0mm, 334.4mm
|
Chainstay Length |
430mm, 432mm
|
430mm, 432mm
|
430mm, 432mm
|
430mm, 432mm
|
Wheelbase |
1155mm, 1157mm
|
1178mm, 1180mm
|
1200mm, 1202mm
|
1223mm, 1224mm
|
Standover |
652mm
|
681mm
|
701mm
|
715mm
|
Reach |
416mm
|
433mm
|
451mm
|
468mm
|
Stack |
589mm
|
602mm
|
614mm
|
627mm
|
Additional Info | All specifications listed are with 160mm travel fork. Geometry adjustable via flip chip in linkage. |
Wheel Trave | 151mm |
Rear Shock | 200 x 57mm (7.875" x 2.25") |
Shock Hardware | 8 x 22mm |
Fork Axle to Crown | 552mm |
Fork Offset | 42mm |
Headtube | Tapered 1 1/8" - 1 1/2" |
Headset | Upper ZS/44 Lower ZS/62mm Tapered OD |
Seatpost Diameter | 30.9mm |
Seatclamp Diameter | 34.9mm |
Rear Wheel Diameter | 27.5" |
Maximum Rear Tire Size | 2.4" |
Bottom Bracket Shell | 73mm Threaded |
Chainline | 49mm |
Chainguide Mount | ISCG05 Lower |
Maximum Chainring Size | Round: 36T / Oval: 34T |
Minimum Chainring Size | Round: 30T / Oval: 32T |
Rear Wheel Spacing | 142mm x 12mm |
Front Derailleur | Single Ring Only |
Rear Brake Mount Type | Post Mount 180mm |
Maximum Rear Rotor Size | 203mm |
