| GEOMETRY | SMALL | MEDIUM | LARGE | X-LARGE |
|---|---|---|---|---|
| A - Head Tube Angle - LOW | 65.3° | 65.3° | 65.3° | 65.3° |
| A - Head Tube Angle - X-LOW | 64.7° | 64.7° | 64.7° | 64.7° |
| B - Seat Tube Angle - LOW | 78.2° | 78.2°° | 78.2° | 78.2° |
| B - Seat Tube Angle - X-LOW | 77.5° | 77.5° | 77.5° | 77.5° |
| C - Virtual Top Tube Length | 590mm | 23.23" | 607mm | 23.90" | 628mm | 24.75" | 650mm | 25.57" |
| C - Virtual Top Tube Length - X-LOW | 593mm | 23.35" | 610mm | 24.01" | 631mm | 24.84" | 652mm | 25.67" |
| D - Seat Tube Length | 390mm | 15.35" | 425mm | 16.73" | 460mm | 18.11" | 495mm | 19.49" |
| E - Bottom Bracket Height - LOW | 349mm | 13.75" | 349mm | 13.75" | 349mm | 13.75" | 349mm | 13.75" |
| E - Bottom Bracket Height - X-LOW | 341mm | 13.43" | 341mm | 13.43" | 341mm | 13.43" | 341mm | 13.43" |
| F - Bottom Bracket Drop - LOW | 8mm | 0.30" | 8mm | 0.30" | 8mm | 0.30" | 8mm | 0.30" |
| F - Bottom Bracket Drop - X-LOW | 16mm | 0.64" | 16mm | 0.64" | 16mm | 0.64" | 16mm | 0.64" |
| G - Head Tube Length | 104mm | 4.09" | 114mm | 4.49" | 127mm | 5.00" | 139mm | 5.47" |
| H - Chain Stay Length - LOW | 430mm | 16.93" | 430mmn | 16.93" | 430mmn | 16.93" | 430mmn | 16.93" |
| H - Chain Stay Length - X-LOW | 432mm | 17.01mm | 432mm | 17.01mm | 432mm | 17.01mm | 432mm | 17.01mm |
| I - Wheel Base - LOW | 1211mm | 47.69" | 1233mm | 48.53" | 1258mm | 49.53" | 1283mm | 50.52" |
| I - Wheel Base - X-LOW | 1213mm | 47.76" | 1235mm | 48.61" | 1260mm | 49.61" | 1285mm | 50.60" |
| J - Axle to Crown | 577mm | 22.72" | 577mm | 22.72" | 577mm | 22.72" | 577mm | 22.72" |
| K - Offset | 44mm | 1.73" | 44mm | 1.73" | 44mm | 1.73" | 44mm | 1.73" |
| L - Front to Center - LOW | 781mm | 30.76" | 803mm | 31.60" | 828mm | 32.60" | 853mm | 33.59" |
| L - Front to Center -X-LOW | 781mm | 30.76" | 803mm | 31.60" | 828mm | 32.60" | 853mm | 33.59" |
| M - Trail - LOW | 116mm | 4.55" | 116mm | 4.55" | 116mm | 4.55" | 116mm | 4.55" |
| M - Trail - X-LOW | 120mm | 4.73" | 120mm | 4.73" | 120mm | 4.73" | 120mm | 4.73" |
| N - Stack - LOW | 612mm | 24.09" | 621mm | 24.44" | 632mm | 24.89" | 643mm | 25.31" |
| N - Stack - X-LOW | 617mm | 24.28" | 626mm | 24.64" | 637mm | 25.09" | 648mm | 25.52" |
| O - Reach - LOW | 456mm | 17.94" | 473mm | 18.60" | 492mm | 19.39" | 512mm | 20.17" |
| O - Reach - X-LOW | 449mm | 17.67" | 466mm | 18.34" | 486mm | 19.12" | 506mm | 19.91" |
| P - Standover - LOW | 692mm | 27.24" | 703mm | 27.67" | 711mm | 28.00" | 724mm | 28.51" |
| P - Standover - X-LOW | 686mm | 27.00" | 696mm | 27.42" | 704mm | 27.72" | 718mm | 28.25" |
| GEOMETRY | SMALL | MEDIUM | LARGE | X-LARGE |
|---|---|---|---|---|
| A - Head Tube Angle - LOW | 64.2° | 64.2° | 64.2° | 64.2° |
| A - Head Tube Angle - X-LOW | 63.5° | 63.5° | 63.5° | 63.5° |
| B - Seat Tube Angle - LOW | 76.9° | 76.9° | 76.9° | 76.9° |
| B - Seat Tube Angle - X-LOW | 76.2° | 76.2° | 76.2° | 76.2° |
| C - Virtual Top Tube Length | 595mm | 23.44" | 612mm | 24.09" | 633mm | 24.92" | 654mm | 25.76" |
| C - Virtual Top Tube Length - X-LOW | 598mm | 23.55" | 615mm | 24.21" | 636mm | 25.03" | 657mm | 25.86" |
| D - Seat Tube Length | 390mm | 15.35" | 425mm | 16.73" | 460mm | 18.11" | 495mm | 19.49" |
| E - Bottom Bracket Height - LOW | 358mm | 14.09" | 358mm | 14.09" | 358mm | 14.09" | 358mm | 14.09" |
| E - Bottom Bracket Height - X-LOW | 349mm | 13.75" | 349mm | 13.75" | 349mm | 13.75" | 349mm | 13.75" |
| F - Bottom Bracket Drop - LOW | 1mm | 0.04" | 1mm | 0.04" | 1mm | 0.04" | 1mm | 0.04" |
| F - Bottom Bracket Drop - X-LOW | 8mm | 0.30" | 8mm | 0.30" | 8mm | 0.30" | 8mm | 0.30" |
| G - Head Tube Length | 104mm | 4.09" | 114mm | 4.49" | 127mm | 5.00" | 139mm | 5.47" |
| H - Chain Stay Length - LOW | 430mm | 16.93" | 430mmn | 16.93" | 430mmn | 16.93" | 430mmn | 16.93" |
| H - Chain Stay Length - X-LOW | 432mm | 17.01mm | 432mm | 17.01mm | 432mm | 17.01mm | 432mm | 17.01mm |
| I - Wheel Base - LOW | 1215mm | 47.84" | 1236mm | 48.68" | 1262mm | 49.68" | 1287mm | 50.69" |
| I - Wheel Base - X-LOW | 1217mm | 47.92" | 1238mm | 48.74" | 1264mm | 49.77" | 1289mm | 50.75" |
| J - Axle to Crown | 586mm | 23.07" | 586mm | 23.07" | 586mm | 23.07" | 586mm | 23.07" |
| K - Offset | 44mm | 1.73" | 44mm | 1.73" | 44mm | 1.73" | 44mm | 1.73" |
| L - Front to Center - LOW | 785mm | 31.91" | 806mm | 31.74" | 832mm | 32.75" | 857mm | 33.74" |
| L - Front to Center -X-LOW | 785mm | 31.91" | 806mm | 31.74" | 832mm | 32.75" | 857mm | 33.74" |
| M - Trail - LOW | 131mm | 5.18" | 131mm | 5.18" | 131mm | 5.18" | 131mm | 5.18" |
| M - Trail - X-LOW | 136mm | 5.36" | 136mm | 5.36" | 136mm | 5.36" | 136mm | 5.36" |
| N - Stack - LOW | 621mm | 24.44" | 630mm | 24.80" | 642mm | 25.26" | 652mm | 25.69" |
| N - Stack - X-LOW | 626mm | 24.63" | 635mm | 24.99" | 647mm | 25.46" | 658mm | 25.89" |
| O - Reach - LOW | 443mm | 17.19" | 460mm | 18.12" | 480mm | 18.91" | 500mm | 19.69" |
| O - Reach - X-LOW | 437mm | 17.45" | 453mm | 17.85" | 473mm | 18.64" | 493mm | 19.42" |
| P - Standover - LOW | 705mm | 27.76" | 716mm | 28.17" | 724mm | 28.50" | 736mm | 28.99" |
| P - Standover - X-LOW | 699mm | 27.54" | 709mm | 27.93" | 718mm | 28.25" | 718mm | 28.25" |
| Available Sizes | Small, Medium, Large, XLarge |
| Available Colors | Clean Slate |
| Wheel Travel | 168mm |
| Rear Shock | Rockshox Super Deluxe Coil Ultimate, Trunnion 205x65, ML 320 |
| Shock Hardware | Trunnion Upper, 20x8mm Lower |
| Fork Axle to Crown | 577mm, Rockshox Zeb 180mm, 27.5" | 586mm, Rockshox Zeb 170mm, 29" |
| Fork Offset | 44mm |
| Headtube | Tapered 1 1/8" - 1 1/2" |
| Headset | Works Components 1 Degree Angleset |
| Seatpost Diameter | 30.9.mm |
| Seatclamp Diameter | 34.9mm |
| Rear Wheel Diameter | 27.5" |
| Maximum Rear Tire Size | 27.5" x 2.6" (Varies By Brand) |
| Bottom Bracket Shell | 73mm Threaded |
| Chainline | 55mm |
| Chainguide Mount | Evil Proprietary Upper, ISCG05 Lower |
| Maximum Chainring Size | 36T Single Ring |
| Minimum Chainring Size | 30T |
| Derailleur Hanger | SRAM Universal Derailleur Hanger |
| Rear Wheel Spacing | 157mm x 12mm |
| Brake Mount Type | Post Mount 180mm |
| Maximum Rear Rotor Size | 203mm |
