| Geometry | S | M | L | XL |
| A HAΒ | 67.5Λ | 67.5Λ | 67.5Λ | 67.5Λ |
| B ST AngleΒ | 71.0Λ | 71.0Λ | 71.0Λ | 71.0Λ |
| C Virtual TT Length | 570mm | 22.4β | 595mm | 23.4β | 615mm | 24.2β | 640mm | 25.2β |
| D ST Length | 350mm | 13.8β | 430mm | 16.9β | 480mm | 18.9β | 500mm | 19.7β |
| E BB HeightΒ (26x2.4" Tire) | 322.5mm | 12.7β | 322.5mm | 12.7β | 322.5mm | 12.7β | 322.5mm | 12.7β |
| F HT Length | 110mm | 4.3β | 110mm | 4.3β | 125mm | 4.9β | 125mm | 4.9β |
| G CS Length Min | 412mm | 16.2β | 412mm | 16.2β | 412mm | 16.2β | 412mm | 16.2β |
| Β Β Β CS Length Max | 428mm | 16.9β | 428mm | 16.9β | 428mm | 16.9β | 428mm | 16.9β |
| H WB Min | 1057mm | 41.6β³ | 1082mm | 42.6β³ | 1103mm | 43.4β³ | 1128mm | 44.4β³ |
| Β Β Β WB Max | 1073mm | 42.3β³ | 1098mm | 43.2β³ | 1119mm | 44.1β³ | 1144mm | 45.1β³ |
| J Axle to Crown (140mm Fork) | 510mm | 510mm | 510mm | 510mm |
| K Offset | 39mm | 39mm | 39mm | 39mm |
| Stack | 574mm | 22.6β³ | 574mm | 22.6β³ | 588mm | 23.2β³ | 588mm | 23.2β³ |
| Reach | 372mm | 14.7β³ | 397mm | 15.6β³ | 412mm | 16.2β³ | 437mm | 17.2β³ |
| SizesΒ | S, M, L, XL |
| Fork A-C height | 510.9mm (140mm) |
| Fork offset | 39mm |
| head tube type (zerostack, regular, drop-in, 1.5) | integrated 1 1/8" Campagnolo style |
| headset spec | FSA Impact 1 1/8" |
| F.D. Clamp diameter | 34.9mm |
| Seat post diameter | 31.6mm |
| Seat clamp type or diameter (DIA or integrated) | 34.9mm |
| MAX Rear tire width | 26x2.5" |
| BB shell width | 73mm |
| Chainline | 50mm |
| # of front chainrings | 1-3 |
| Crank length | 175mm |
| Chainguide mount | ISCG05 |
| MAX chainring | 44T |
| Chainring spec | 44/32/22T |
| Rear wheel spacing | 142x12 |
| Disc brakes, V-brakes, or both | disc only |
| MAX Rear disc diameter (if applicable) | 185mm |
| Specific derailleur hanger (if applicable) | HVS |
