| Size |
S (Low, X-Low)
|
M (Low, X-Low)
|
L (Low, X-Low)
|
XL (Low, X-Low)
|
|---|---|---|---|---|
| Top Tube Length |
604mm
|
624mm
|
647mm
|
671mm
|
| Head Tube Angle |
66.1°, 65.5°
|
66.1°, 65.5°
|
66.1°, 65.5°
|
66.1°, 65.5°
|
| Head Tube Length |
104mm
|
114mm
|
127mm
|
139mm
|
| Seat Tube Angle |
74.8°, 73.9°
|
74.8°, 73.9°
|
74.8°, 73.9°
|
74.8°, 73.9°
|
| Seat Tube Length |
390mm
|
425mm
|
460mm
|
495mm
|
| Bottom Bracket Height |
348mm, 339mm
|
348mm, 339mm
|
348mm, 339mm
|
348mm, 339mm
|
| Chainstay Length |
430mm, 432mm
|
430mm, 432mm
|
430mm, 432mm
|
430mm, 432mm
|
| Wheelbase |
1161mm, 1162mm
|
1182mm, 1183mm
|
1207mm, 1208mm
|
1232mm, 1233mm
|
| Standover |
734mm
|
745mm
|
752mm
|
765mm
|
| Reach |
415mm
|
432mm
|
452mm
|
472mm
|
| Stack |
627mm
|
636mm
|
648mm
|
659mm
|
| Additional Info | All specifications listed are with 160mm fork. | |||
| Wheel Trave | 161mm |
| Rear Shock | 216mm x 63mm (8.5" x 2.5") |
| Shock Hardware | 8 x 22mm |
| Fork Axle to Crown | 571mm |
| Fork Offset | 51mm |
| Headtube | Tapered 1 1/8" - 1 1/2" |
| Headset | Upper ZS/44 Lower ZS/62mm Tapered OD |
| Seatpost Diameter | 30.9mm |
| Seatclamp Diameter | 34.9mm |
| Rear Wheel Diameter | 29" |
| Maximum Rear Tire Size | 2.4" |
| Bottom Bracket Shell | 73mm Threaded |
| Chainline | 51mm |
| Chainguide Mount | ISCG05 Lower |
| Maximum Chainring Size | Round: 36T / Oval: 34T |
| Minimum Chainring Size | Round: 30T / Oval: 32T |
| Rear Wheel Spacing | Boost 148mm x 12mm |
| Front Derailleur | Single Ring Only |
| Rear Brake Mount Type | Post Mount 180mm |
| Maximum Rear Rotor Size | 203mm |
